Product Details
  • Size:  200CBM
  • Place of Origin:  CHINA
  • Brand Name:  Sheiley
  • Model Number:  SILO
  • Weight: 10000.000 kg

Steel Grain Silos

Assembly Corrugated Galvanizing Steel Silos

Early 80s ,the first Assembly Corrugated Galvanizing Steel Silos came out ,assembly body sheets of these silos are made up of molded steel sheets and vertical stiffeners B style.

As to small or short silos , unit stiffeners could take the place of  vertical stiffeners (a vertical stiffener VS a wall sheet). But when it comes to large or tall silos , double stiffeners are required

Further more , from top to the bottom, thickness of stiffeners shall get thicker and thicker

From top to the bottom ,thickness of molded steel sheets on each rings shall also become thicker.

 Before packing and transporting to store or sites.

wall sheets shall be dealt with punching , bending and galvanizing procedure .



A world leader in steel corrugated storage bin supplying, TSE offers the strongest and heaviest storage silos in the industry with capacities exceeding 15,000 MT. Our silo sidewall is roll-formed using high quality galvanized steel sheets; Prime high tensile steel up to 450 MPa. Thicker sidewall steel sheet allows us to provide larger silos with our designs.

Grain silo includes ROOF,BODY,ROOF,HANDRAIL,VENTS,MANHOLE,DOOR;

The silo roof and body is made of corrugated galvanizing steel sheets, the galvanizing mass is 275g/ as standard design, according to some customers special request, 350g/ and 400g/ are options for their needs;

Silo is anti-seismic.



Features of thermal insulation silo

Thermal insulation

Grain temperature change gradient inside silos is lower than that outside,thus not likely to have condensation of moisture.

Safe grain storage

Storing in a low temperature,increase the grain storage stability,keeps the grain quality and prolongs the safe-storage period

Low fabrication cost

With installing an insulation layer(Polyurethane froth,rubber single,glass fiber etc.) on the outer wall,insulation silo can have a low fabrication cost compared to concrete silo.



  • Size:  200CBM
  • Place of Origin:  CHINA
  • Brand Name:  Sheiley
  • Model Number:  SILO
  • Weight: 10000.000 kg
